Board to Board Connector

Browse male pin headers and female headers for board-to-board connections. Select the two mating parts together to suit the contact arrangement and relative position of your PCBs.

Filter & Product Results

109 productsPage 3 of 6

Filter products

Features

The range includes straight and right-angle headers, SMT and through-hole mounting, and different pitches and row arrangements. Compare these details on each part; not every configuration is available on both sides of a connection.

Selection Guidance

Start with the required board position and assembly direction. Then narrow the header and socket by pitch, rows and contact count. Check the footprint on each PCB, confirm the assembled board spacing from the selected pair’s drawings, and allow clearance for mating and removal.

Frequently Asked Questions

Does matching pitch guarantee that a header and socket will mate?

No. Pin shape and dimensions, row spacing, contact arrangement and insertion depth also need to match. Confirm the intended pair before finalising the PCB footprints.

Is housing height the same as the distance between connected boards?

Do not use housing height alone as the board spacing. The assembled spacing depends on both connectors and their engagement. Confirm that dimension on the drawings for the selected pair.

What if a required rating or dimension is not listed?

Ask us to confirm it for the specific header and socket under consideration. Include the required value and both product references; do not assume that a nearby size or similar-looking part has the same specification.

Need a configuration not shown?

Include the part number, mating connector, key dimensions and required quantity in your inquiry.
