USB Connector

Browse USB Type-A, Type-B, Type-C and Micro USB connectors, together with connector shells and cable options. Start with the mating interface, then compare the selected product’s USB version, contact arrangement and mounting details.

Filter & Product Results

152 productsPage 1 of 8

Filter products

Features

PCB options include straight and right-angle orientations, through-hole, DIP and SMT mounting, and selected offset, flag and board-edge constructions. Compare single and dual-port configurations where specified. Type-C shells are separate selection items: match their dimensions to the intended connector assembly.

Selection Guidance

First match the interface and gender at the connection. Next compare contact count, board footprint or cable-end configuration. Finally check the connector position, fixing features and mating clearance on the drawing. Keep required data, charging and display functions separate from the physical fit, and confirm them for the selected part and complete design.

Frequently Asked Questions

What should I do when a connector drawing is missing?

Request the drawing using the product reference and identify the dimension you need. We need to confirm the relevant footprint or outline before the part can be checked for mechanical fit.

How do I specify a USB cable connection?

Identify the interface and gender at both ends, the required length and the pin-to-pin wiring. For angled or panel-mounted ends, include the plug direction and panel dimensions.

What needs checking for a sealed USB connection?

Confirm the selected part’s protection rating and the mating and installation conditions under which it applies. Include the required exposure conditions when requesting the supporting information.

Need a configuration not shown?

Include the part number, mating connector, key dimensions and required quantity in your inquiry.
