D sub 26 Pin Male Straight Staking type Through Hole for PCB Mount Connector

D sub 26 Pin Male Straight Staking type Through Hole for PCB Mount Connector
D sub 26 Pin Male Straight Staking type Through Hole for PCB Mount Connector D sub 26 Pin Male Straight Staking type Through Hole for PCB Mount Connector D sub 26 Pin Male Straight Staking type Through Hole for PCB Mount Connector D sub 26 Pin Male Straight Staking type Through Hole for PCB Mount Connector D sub 26 Pin Male Straight Staking type Through Hole for PCB Mount Connector

Part NO.:RHT-681-1213
Tags: D-sub,High Density,Straight/180°,26Pin,Staking type,Mechined Pin,PCB Mount,Through Hole,White

Features:

  • Precision turned contacts
  • D-sub tinned and dimpled shell options – for enhanced electrical continuity and effective EMI/RFI shielding
  • 12 Months Quality Insurance
  • Free sample available for quality test
  • Can be Customized for unique material or performance requirement
Get A Free Quote

Major Technical Characteristics
Voltage Rating 300 V AC/rms 50Hz
Withstanding Voltage 1000V AC/ rms 50Hz for one minute
Insulation Resistance 5000MΩ
Contact Resistance 8.5mΩ max. DF: 5mΩ max
Operating Temperature D: -67°F (-55°C) to +185°F (85°C),

DF: -67°F (-55°C) to + 257°F (125°C)
