USB Connector

Type C Reversible Connector USB 3.0 SMT for PCB Mount

Public Part No. RHT-692-1266

Type C Reversible Connector USB 3.0 SMT for PCB Mount
Enlarge image
Type C Reversible Connector USB 3.0 SMT for PCB MountType C Reversible Connector USB 3.0 SMT for PCB MountType C Reversible Connector USB 3.0 SMT for PCB MountType C Reversible Connector USB 3.0 SMT for PCB MountType C Reversible Connector USB 3.0 SMT for PCB MountType C Reversible Connector USB 3.0 SMT for PCB MountType C Reversible Connector USB 3.0 SMT for PCB Mount

Key specifications

Connector Type
USB3.0 / Type C
Gender
Female
Orientation
Right Angle
Mounting Type
PCB Mount / SMT
Request QuoteFull specifications

Overview

USB Connector with Female, Right Angle, Type C / USB3.0. Mounting: SMT, PCB Mount.

Offset construction. Compare the offset position with the mechanical drawing and available assembly space.

Full Specifications

Electrical

Current Rating
5A
Voltage Rating
5V AC
Contact Resistance
40 milliohms max
Insulation Resistance
100 megohms
Withstanding Voltage
100V AC

Mechanical

Connector Type
USB3.0 / Type C
Gender
Female
Orientation
Right Angle
Mounting Type
PCB Mount / SMT
Construction detail
Offset Type
Connection feature
Reversible plug and cable orientation
Mating force
5N to 20N
Unmating Force
8N to 20N
Durability
10,000 mating cycles

Environmental

Operating Temperature
-30 to 85 °C

Connector requirement

Request a quote

Share your connector requirements and the specifications you need.

    Inquiry details

    Attach one PDF, JPEG or PNG, up to 5 MB.

    Include the details needed to help with your connector inquiry. You can check them before sending.
