Terminal Blocks

Spring Push Terminal Block 4pin Green Through Hole Straight Crimp Cable Connector

Part No.RHT-665-2014
4-pin green spring terminal block with straight orientation, 5.08 mm pitch, through-hole mounting. Cage-clamp connection. Rated current 10 A; rated voltage 300 V.
  • Connector TypeCable Connector / Cage Clamp Type
  • Pin Count4 Pin
  • OrientationStraight

Include quantity, mating equipment and installation requirements.

Product data

The connection, at a glance.

Electrical

Current Rating
10A
Voltage Rating
300V

Connection

Connector Type
Cable Connector / Cage Clamp Type

Mechanical

Pin Count
4 Pin
Orientation
Straight
Mounting Type
Through Hole
Pitch
5.08 mm

Material

Color
Green

Before you specify

Selection guide

4-pin green spring terminal block with straight orientation, 5.08 mm pitch, through-hole mounting. Cage-clamp connection. Rated current 10 A; rated voltage 300 V.

RHT-665-2014
