Cable Assembly

SlimSAS SFF-8654 8i Cable, Right angle to right angle

Part No.RHT-726-1016

Cable assembly from SlimSAS SFF-8654 8i to SlimSAS SFF-8654 8i. Includes right angle connector A and right angle connector B.

  • Connector TypeSlimSAS
  • Connector ASlimSAS SFF-8654 8i
  • Connector BSlimSAS SFF-8654 8i

Include quantity, mating equipment and installation requirements.

Product data

The connection, at a glance.

Check the documents ↗

Connection

Connector Type
SlimSAS
Connector A
SlimSAS SFF-8654 8i
Connector B
SlimSAS SFF-8654 8i
Connector A quantity
1
Connector B quantity
1

Mechanical

Connector A orientation
Right angle
Connector B orientation
Right angle

Material

Signal wire gauge
32 AWG

Engineering resources

Check fit and wiring.

1 product document

Before you specify

Selection guide

Cable assembly from SlimSAS SFF-8654 8i to SlimSAS SFF-8654 8i. Includes right angle connector A and right angle connector B.

Both SlimSAS 8i connectors use right-angle exits. Check the orientation of each mating connector, since the two cable exits must suit the installed layout.

Configuration details

  • Connector A orientation: Right angle.
  • Connector B orientation: Right angle.
  • Signal wire gauge: 32 AWG.

Selection information

Provide the mating connector references, required pin assignment and cable length when requesting a quotation.

RHT-726-1016
