Pin Header Connector

Round Pin Headers Straight Double Row 2.54mm DIP Type

Part No.RHT-603-3052

6-contact dual-row male header with 2.54 mm pitch; straight through-hole mounting. Dimension H: 3 mm.

  • Pin Count6 Pin
  • GenderMale
  • OrientationStraight

Include quantity, mating equipment and installation requirements.

Product data

The connection, at a glance.

Electrical

Current Rating
1.5A
Insulation Resistance
1000M ohms min
Dielectric Withstanding
AC500V

Mechanical

Pin Count
6 Pin
Gender
Male
Orientation
Straight
Mounting Type
DIP / Through Hole
Termination Type
Solder Type
Pitch
2.54 mm
Number of Rows
Dual Row
Construction detail
Circular
Dimension H
3 mm

Material

Contact Plating
Tin Plating
Color
Black
Plating layers
Gold (Au) plated (surface flashing); Tin-plated (main plating materials); Nickel(Ni) plated (underplating)

Before you specify

Selection guide

Pin Header Connector with 6 Pin, Male, Straight. Mounting: Through Hole, DIP.

Termination Type: Solder Type. Pitch: 2.54 mm.

This dual-row header has round pins. Dimension H is 3 mm.

RHT-603-3052
