Pin Header Connector

3 Row Pin Header 180 Degree 9 Way Through Hole

Public Part No. RHT-603-3031

3 Row Pin Header 180 Degree 9 Way Through Hole
Enlarge image
3 Row Pin Header 180 Degree 9 Way Through Hole3 Row Pin Header 180 Degree 9 Way Through Hole3 Row Pin Header 180 Degree 9 Way Through Hole3 Row Pin Header 180 Degree 9 Way Through Hole

Key specifications

Pin Count
9 Pin
Gender
Male
Orientation
Straight
Mounting Type
Through Hole
Termination Type
Solder Type
Request QuoteFull specifications

Overview

Pin Header Connector with 9 Pin, Male, Straight. Mounting: Through Hole.

Termination Type: Solder Type. Pitch: 2.54 mm.

The 9 contacts are arranged in three rows.
