Cable Assembly

Mini-SAS HD SFF-8643 8i Cable

Public Part No. RHT-726-3002

Mini-SAS HD SFF-8643 8i Cable
Enlarge image

Key specifications

Connector Type
Mini-SAS HD
Request QuoteFull specifications Downloads

Overview

Cable assembly from Mini-SAS HD SFF-8643 8i to Mini-SAS HD SFF-8643 8i.

Both ends use the 8i Mini-SAS HD configuration. Check the complete mating footprint and the cable route between the two connections.

Selection information

Provide the mating connector references, required pin assignment and cable length when requesting a quotation.

Full Specifications

Mechanical

Connector Type
Mini-SAS HD
Connector A
Mini-SAS HD SFF-8643 8i
Connector B
Mini-SAS HD SFF-8643 8i
Connector A quantity
1
Connector B quantity
1

Downloads

Drawing (PDF)
