D-SUB Connector
DB 15 Pin Stacked 90 Degree Female and 9 Pin Male Connector for PCB Mount
- Connector TypeD-SUB Connector
- OrientationRight Angle
- Mounting TypePCB Mount / Through Hole
Include quantity, mating equipment and installation requirements.
Product data
The connection, at a glance.
Electrical
- Current Rating
- 3A
- Voltage Rating
- 60V
- Contact resistance
- 10 mOhm
- Dielectric Withstanding Voltage (Signal)
- 1000 V
Connection
- Connector Type
- D-SUB Connector
Mechanical
- Orientation
- Right Angle
- Mounting Type
- PCB Mount / Through Hole
- Termination Type
- Staking Type
- Shielding
- Shielded
- Construction detail
- Stacked / stacked
- Extraction force
- <50 N
- Insertion force
- <50 N
- Mating cycles
- 50
- Pin Count at connector ends
- 15 Pin / 9 Pin
- Gender at connector ends
- Female / Male
Material
- Shell construction
- Metal shell
Environmental
- Operating Temperature
- -55 to 105 °C
Before you specify
Selection guide
Stacked D-SUB connector with a 15-pin female interface and a 9-pin male interface in a right-angle configuration. Termination: staking type.
RHT-681-1206
Ready to specify your connection?
Share the equipment, dimensions and quantity you need.
Connector requirement
Request a quote
Share your connector requirements and the specifications you need.
DB 15 Pin Stacked 90 Degree Female and 9 Pin Male Connector for PCB Mount- Product family
- D-SUB Connector
- Public Part No.
- RHT-681-1206
